OEG Offshore Personnel Baskets have been designed and manufactured in accordance with DNV2.7-1 / BS EN 12079. The units are supplied with certified slings and shackles as standard. Internal tie down points through out the interior provide strong points for safety harness lock off for personnel during operations.
Certificates
SAFE TRANSFER® CERTIFICATES
- DNV GL – Type Approval Certificate Standard for Certification 2.22 Lifting Aplliances
- Danish Technological Institute (Notified Body)
- European Standard EN 14502-1:2010 Cranes-Equipment for lifting of persons Part 1. suspended baskets
- NDT and load test
- Certified chain lifting sling
- ISO 9001:2008 certification of the entire development, manufacturing and sale process.
4 persons version
SPECIFICATIONS
- Diameter: 2600 mm
- Height: 3222 mm
- Weight: 465 kg
- Capacity: 4 persons
- Max. load (payload): 500 kg
8 persons version
SPECIFICATIONS
- Diameter: 2600 mm
- Height: 3340 mm
- Weight: 510 kg
- Capacity: 8 persons
- Max. load (payload): 1000 kg
